Stiebel Eltron
Stiebel Eltron DHCE 8/60 Single Phase 9.5kW 50deg
Regular price
$898.00
Regular price
Sale price
$898.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Product Details
Modern design
- Modern carbon look design
- Electronically controlled
- Three selectable temperature outputs for greater convenience
- Tubular heating element
- WaterMark approved, Lic. No. WMKA21273, AS3498
Installation flexibility
- Delivers a maximum of 50°C hot water in accordance with AS3498
- No safe tray or drainage required (check local regulations)
- Space saving compact design
Save water and energy
The DHCE compact water heater utilises electronic control that helps to save energy and water compared to older style hydraulically controlled instantaneous water heaters.
In addition, the compact design allows for close to the point of use installation to help save water by reducing the time it takes to deliver hot water to the outlet. The advantage of an instantaneous water heater is that no heat is lost, and energy wasted, to store hot water at temperature. Energy is only required to heat water when the hot water outlet is switched on.
Available in two electrical sizes:
- DHCE 6/50 - 7.1kW, 30 Amps, single phase 240V
- DHCE 8/50 - 9.5kW, 40 Amps, single phase 240V
Warranty
- 5 year full parts and labour domestic warranty*
Technical Data
| Model number | DHCE 6/50 | DHCE 8/50 |
| Rated output (240V) | 7.1kW | 9.5kW |
| Rated current (240V) | 30Amp | 40Amp |
| Phases | 1/N/PE/AC 220..240V | 1/N/PE/AC 220..240V |
| Electrical Installation | As per AS/NZS3000 | |
| Installation requirements | AS/NZS3500.4.2 & local requirements | |
| Switch on flow rate (minimum flow rate required to switch on the water heater) | 1.5L/min | 1.5L/min |
| Permissible operating pressure | 1000kPa | 1000kPa |
| Temperature adjustment | 40°C 45°C 50°C | 40°C 45°C 50°C |
| IP Rating | IP25 | IP25 |
| Height | 360mm | 360mm |
| Width | 200mm | 200mm |
| Depth | 110mm | 110mm |
| Weight (filled with water) | 2.45kg | 2.45kg |
| Colour | Silver look | Silver look |
| Nominal capacity | 0.45L | 0.45L |
| Approvals | WaterMark Lic No. WMKA21273, AS3498 | |
| For one/several draw off points | Yes/Yes | Yes/Yes |
| Heating system | Tubular | Tubular |
| Electronic flow rate control | No | No |
| Electronic air detection system | No | No |
| Programmable temperature | No | No |
| Temperature Rise (240 V) | DHCE 6/50 | DHCE 8/50 |
| 4 L/min | +25°C | +33 °C |
| 5 L/min | +20 °C | +27 °C |
| 6 L/min | +16 °C | +22 °C |
| 7 L/min | +14 °C | +19 °C |
| 9 L/min | +11 °C | +15 °C |
